16x4 Character LCD Module 87x60mm for GPS Navigator Systems
Product Details:
Payment & Shipping Terms:
| Minimum Order Quantity: | 500 |
|---|---|
| Price: | 35 |
|
Detail Information |
|||
| Model NO.: | RY010 | Response Time: | 30ms |
|---|---|---|---|
| Display Technology: | COB | LCD Drive Mode: | Multiplex Drive LCD Module |
| Outline Dimensions: | 87*60 Mm | Viewing Area: | 61.7*25.2 Mm |
| LCD Type: | FSTN-Positive, Stn-Gray | Driver IC: | St7066u |
| Character Format: | 16x4 | Viewing Angle: | 6 O' Clock |
| Backlight Type: | White Or Amber LED | Power Supply: | 5.0V |
| Interface Type: | Parallel | Operating Temperature: | -30º C~70ºC |
| Storage Temperature: | -30º C~80ºC | ||
| Highlight: | 16x4 character LCD module for GPS,87x60mm LCD display module,TFT LCD module for navigator systems |
||
Product Description
| Attribute | Value |
|---|---|
| Model NO. | RY010 |
| Response Time | 30ms |
| Display Technology | COB |
| LCD Drive Mode | Multiplex Drive LCD Module |
| Customized | Customized |
| Outline (mm) | 87*60 |
| Viewing Area(mm) | 61.7*25.2 |
| LCD Type | FSTN-Positive, Stn-Gray |
| Driver IC | St7066u |
| Transport Package | Plastic Plate |
| Specification | 16x4 Character |
| Trademark | Royal Display |
| Origin | China |
| HS Code | 9013803010 |
| Production Capacity | 300K/Month |
| Item | Description |
|---|---|
| Product Name | Big 16X4 Character LCD Module |
| Model No. | RYP1604A |
| Dot Format | 16X4 |
| Outline (mm) | 87*60 |
| Viewing Area(mm) | 61.7*25.2 |
| Viewing Angle | 6 O' clock |
| LCD Type | FSTN-Positive, STN-Gray |
| Backlight | White or Amber LED backlight |
| Driver IC | ST7066U |
| Power supply | 5.0V |
| Interface | Parallel |
| Operating Temp | -30º C~70ºC |
| Storage Temp | -30º C~80ºC |
Royal Display Co., Ltd has been specializing in LCD business for more than 10 years, offering products including LCD Display, LCD Screen, LCD Module, Character LCD, LED backlight display, TFT display, Graphic LCD, and 7 segment LED Display.
More than 90% of our products are custom-designed for applications in Video/Audio systems, financial, medical, and industrial equipment, testing devices, electronic meters, facsimiles, and various terminal equipment. With a production capacity of 300K different kinds of LCM/LCD per month.
Our products have passed international quality certifications including CE, FCC & RoHS. With high quality and competitive prices, our products are exported worldwide and well received by customers.
- Quality Control: Every LCD tested with special instruments before delivery
- Packing: Anti-static bags with foam box for safe transportation
- Payment Terms: T/T, Western Union
- Shipping Methods: Prompt delivery via UPS, EMS, DHL, TNT, or air
- Service: Excellent after-sales service
- Delivery: 2-4 days via major carriers
- Warranty: 1-year product warranty
- Samples: Available with sample and freight charges
