5.7'' 320*RGB*240 6H QVGA Wide Temperature Cost-efficient LCD Module
Product Details:
| Place of Origin: | CHINA |
| Brand Name: | Royal Display or ODM/OEM |
| Certification: | SGS, ROHS |
| Model Number: | TM057KDH02 |
Payment & Shipping Terms:
| Minimum Order Quantity: | negotiable |
|---|---|
| Price: | 19.99 USD EXW |
| Packaging Details: | Cartons, Capboard, EPE, Blister Tray. |
| Delivery Time: | 15~25 working day |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 300K pcs/month |
|
Detail Information |
|||
| Luminance: | 400 | Contrast Ratio: | 500 |
|---|---|---|---|
| Operating Temp: | -30 To +85 Celsius Degree | Module Dimension: | 144*104.6*12.3 Mm |
| Uniformity: | 80% | Life Time: | 50,000 Hrs |
| Highlight: | 5.7'' LCD Module,6H QVGA LCD Module |
||
Product Description
5.7'' 320*RGB*240 6H QVGA wide temperature cost-efficient LCD Module
Product Description
| Item | Description |
| Product Name | 5.7'' 320*240 TFT LCD Module |
| Model No. | TM057KDH02 |
| Dot Format | 320RGB(H)x240(V) |
| Outline (mm) | 144*104.6*12.3 mm |
| Active Area(mm) | 115.20*86.40 mm |
| Display Mode | Normally white |
| Pixel Arrangement | RGB-Vertical Stripe |
| Display Color | 262K |
| Driver IC | NV3035C |
| Gray scale inversion Direction | 12 o'clock |
| Viewing Direction | 6 o'clock |
| Brightness | 400 cd/m2 |
| Operating Temp | -20º C~+70ºC |
| Storage Temp | -30º C~+80ºC |
| Contrast Ratio | 500 |
Our Advantages
Over 10-year expert in LCD modules, 20,000m² own factory; 12-month product warranty
OEM/ODM and customization services available, Professional R&D team and overseas sales team
100% inspection before shipment; fast delivery time; Items carry RoHS, CE and SGS marks
Products widely used in instruments and handheld devices, and the medical and automotive industries
Applications
Our lcd module size are from 2.8 inch to 10.1 inch which are widely used in digital camera, dv, security monitoring, carcorder, pmp, mid and education learning aid, pos machine etc.
| Product | Application |
| Small-size tft lcd display (1.44inch~4.3inch) | Mobile device, watch, toy, medical equipment, office electronic equipment, camera, air-condition display, etc. |
| Mid-size tft lcd display (5.0inch~10.0inch) | Mobile device, medical equipment, car, automotive product, industrial control equipment, pos, pda, household video doorbell, air-condition display, etc. |
| Big-size tft lcd display (10inch and above) | Educational product, automotive product, video door phone, audiovisual equipment, dvd player, media play, tablet pc, security products, etc. |
| Tn/stn//fstn/oled | Elevator controller, watch, electronic product, air-condition display, all kinds of instrument, etc. |
| Plastic mould | Industrial control equipment, electronic product, toy, security product, it digital product, sports equipment, etc. |
ABOUT TFT LCD DISPLAY
Thin-Film-Transistor Liquid Crystal Displays (TFTs) are perhaps the most encountered display technology we see daily. Often seen in cell phones, tablets, cameras and countless other devices, this technology offers several hundreds of thousands of colors with a high pixel count to offer supreme visual clarity. In addition, all TFTs are available off the shelf with resistive and capacitive touch panel options.
Features
Broad selection of off the shelf products
Sunlight readable options available
Capacitive and Resistive options available for every display
Most products are kept in stock and can ship same day
Multiple interfaces available
Customizable FPC cables, LED backlights, and bezels
