Innolux 5.6 Inch TFT LCD Module 480x480 Resolution 24bit RGB
Product Details:
Payment & Shipping Terms:
| Minimum Order Quantity: | 500 |
|---|---|
| Price: | 12.99 |
|
Detail Information |
|||
| Screen Size: | 5.6 Inch | Aspect Ratio: | 4:3 |
|---|---|---|---|
| Resolution: | 480X3(RGB)X480 | Module Size: | 126.5 X 100.0 X 5.7 Mm |
| Active Area: | 112.896 X 84.672 Mm | Viewing Angle: | 50/70/70/70 |
| Luminance: | 200 Nits | Contrast Ratio: | 500 |
| Response Time: | 25 Ms | Weight: | 127.5 G |
| Interface: | 50pin FPC, Parallel 24bit RGB | Operation Temperature: | -20º C~70ºC |
| Storage Temperature: | -30º C~80ºC | HTHH (op): | 40ºC 90%RH 240h |
| Feature: | LED Backlight Display | ||
| Highlight: | 5.6 inch TFT LCD module,480x480 resolution LCD display,24bit RGB TFT module |
||
Product Description
Hot Sale 2.1 Inch Transflective Round TFT LCD with SPI 480×480 Resolution
Product Specifications
| Attribute | Value |
|---|---|
| Model NO. | RYP320240B |
| Aspect ratio | 4:3 |
| Feature | LED Backlight Display |
| Optimum Resolution | 320*240 |
| Type | TFT |
| Widescreen | Not Widescreen |
| Response Time | 25ms |
| 3D | Not 3D |
| Interface Type | RGB |
| Product Type | Module |
| Resolution | 480×3(RGB)×480 |
| Module Size(mm) | 126.5 × 100.0 × 5.7 |
| Active Area(mm) | 112.896 × 84.672 |
| Viewing Angle | 50/70/70/70 |
| Interface | 50pin FPC, Parallel 24bit RGB |
| Transport Package | Plastic Plate |
| Specification | 5.6 Inch |
| Trademark | Innolux |
| Origin | China |
| HS Code | 9013803010 |
| Production Capacity | 300K/M |
Detailed Product Information
Innolux, with over 60,000 employees worldwide, operates major TFT plants in Zhunan and Tainan, Taiwan, and has established overseas module plants in Ningbo, Nanjing, Foshan, and Shanghai, China. This global presence enables efficient service delivery while reducing logistics costs and supporting environmental objectives.
| Item | Description |
|---|---|
| Model Name | AT056TN52 V.3 |
| Product type | LCD Module |
| Screen Size | 5.6" |
| Aspect Ratio | 4:3 |
| Resolution | 480×3(RGB)×480 |
| Module Size(mm) | 126.5 × 100.0 × 5.7 |
| Active Area(mm) | 112.896 × 84.672 |
| Viewing Angle (Tpy.)θT/θB/θL/θR | 50/70/70/70 |
| Luminance(nits) | 200 |
| Contrast Ratio | 500 |
| Response Time(ms) | 25 |
| Weight (g) | 127.5 |
| Interface | 50pin FPC,Parallel 24bit RGB |
| Operation Temperature( ºC) | -20º C~70ºC |
| Storage Temperature (ºC) | -30º C~80ºC |
| HTHH.(op) | 40ºC 90%RH 240h |
Product Images
About Royal Display
Royal Display Co., Ltd has specialized in LCD business for over 10 years, offering LCD Displays, LCD Screens, LCD Modules, Character LCDs, LED backlight displays, TFT displays, Graphic LCDs, and 7 segment LED Displays. Over 90% of our products are custom-designed for applications in video/audio systems, financial, medical, and industrial equipment.
Our monthly production capacity reaches 300K different kinds of LCM/LCD. All products meet international quality standards including CE, FCC & RoHS certifications.
Our Advantages
- Quality Control: Every LCD tested with special instruments before delivery
- Packing: Anti-static bags with foam box for safe transportation
- Payment Terms: T/T, Western Union
- Shipping Methods: Prompt delivery via UPS, EMS, DHL, TNT, or air
- Service: Comprehensive after-sales support
- Delivery: 2-4 days via major carriers
- Warranty: Standard one-year product warranty
- Samples: Available for quality testing (sample and freight charges apply)
Application Examples
