8.4'' 1024*768 RGB TFT LVDS Interface High Contrast Bright Wide Temperature LCD Module

Certification
China Royal Display Co.,Limited certification
China Royal Display Co.,Limited certification
Customer Reviews
Royal Display, Perfect LCD Supplier, Fast response, thanks for cooperation.

—— Beata from Poland

Received the lcds today, no damage and test well, thanks.

—— Natalya Kryukova from Russia

Fast delivery and good quality, I am happy with Royal Display, I will order more later.

—— Meerimgul from Turkey

High quality screen, fast service.

—— Daniel Castelo from Switzerland

I'm Online Chat Now

8.4'' 1024*768 RGB TFT LVDS Interface High Contrast Bright Wide Temperature LCD Module

8.4'' 1024*768 RGB TFT LVDS Interface High Contrast Bright Wide Temperature LCD Module
8.4'' 1024*768 RGB TFT LVDS Interface High Contrast Bright Wide Temperature LCD Module 8.4'' 1024*768 RGB TFT LVDS Interface High Contrast Bright Wide Temperature LCD Module

Large Image :  8.4'' 1024*768 RGB TFT LVDS Interface High Contrast Bright Wide Temperature LCD Module

Product Details:
Place of Origin: CHINA
Brand Name: Royal Display or ODM/OEM
Certification: SGS, ROHS
Model Number: P0840XGF1MA00
Payment & Shipping Terms:
Minimum Order Quantity: negotiable
Price: 99.99 USD EXW
Packaging Details: Cartons, Capboard, EPE, Blister Tray.
Delivery Time: 15~25 working day
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 300K pcs/month
Detailed Product Description
Resolution: 1024*768 Pixel Pitch: 0.1665*0.1665 Mm
Display Mode: SFT, Normally Black Module Dimension: 199.5*149*9.7 Mm
Active Area: 170.496*127.872 Mm Contrast Ratio: 1000
Luminance: 1000 NTSC: 70
Highlight:

Wide Temperature TFT LCD Module

,

1024*768 TFT LCD Module

,

8.4'' TFT LCD Module

8.4'' 1024*768 RGB TFT LVDS interface high contrast bright wide temperature LCD Module





Product Description



Item STANDARD Value
LCD size 8.4 inch(Diagonal)
Driver element a-Si TFT active matrix
Resolution 1024 x R.G.B. x 768
Display mode SFT, Normally black
Pixel Pitch 0.1665*0.1665 mm
Active area 170.496*127.872 mm
Contrast Ratio 1000:1
Pixel Arrangement RGB vertical Stripe
Display Colors 16.2M
Interface LVDS
Working Voltage 5v
Surface Treatment Anti Glare
Top & Tst -30˚C ~ +80˚C &-40˚C-~+90˚C

8.4'' 1024*768 RGB TFT LVDS Interface High Contrast Bright Wide Temperature LCD Module 0



Applications

  1. Automotive Displays: The LCD panel can be integrated into automotive infotainment systems, dashboard displays, rear-seat entertainment systems, and navigation systems. It provides clear visuals and touch functionality for enhanced user experience.

  2. Retail and Advertising: The panel can be utilized in retail displays, kiosks, and digital signage to showcase product information, advertisements, and interactive content in stores, malls, and public spaces.

  3. Gaming and Casino Machines: The LCD panel can be incorporated into gaming machines, slot machines, and casino displays, providing vibrant and immersive visuals for gaming enthusiasts.

  4. Financial and Trading Systems: The panel can be used in financial trading platforms, stock market displays, and banking systems, providing real-time data visualization and analysis for traders and financial professionals.

  5. Control Rooms: LCD panels like the G104X1-L04 are suitable for control room applications, such as command centers, surveillance systems, and process monitoring displays, where operators require clear and detailed information.

  6. Education and Training: The panel can be utilized in interactive whiteboards, e-learning systems, and training simulators, providing a visual platform for educational content and interactive learning experiences.

  7. Hospitality and Tourism: LCD panels can be integrated into hotel information displays, self-check-in kiosks, interactive maps, and digital concierge systems, enhancing the guest experience and providing useful information.

  8. Defense: The panel can be used in equipment, including ruggedized displays for vehicles, control panels for aerospace systems, and simulation and training systems for defense personnel.

  9. Public Transportation: LCD panels can be found in transportation hubs, bus and train stations, and airports, displaying real-time schedules, route information, and passenger announcements.

  10. Home Automation: The panel can be integrated into home automation systems, smart mirrors, and touch control panels for smart homes, providing visual feedback and control interfaces for various smart devices.



Our Advantages



1. We specializing in the design, development and production of LCD display module full scheme for more than 10years. Each product undergoes professional design, debugging, production and quality inspection to ensure that the product meets shipping standards.
2. Broad selection of off the shelf products can be chosen and most products are kept in stock and can ship same day.
3. We also offer customed services for you, and can provide drawings and procedures for customers to confirm.
4. Our products offer sunlight readable options , and each display offers capacitive and resistive options
5. We provide reliable warranty service and the warranty preriod is one year.





Packaging & Shipping



Packaging : All the products are packed in right way to keep it safe. For small sizes of products we often use tray + carton, and for bigger sizes we use foam slot + carton. Also we can design packages to meet customers' requirements.

Shipping : For small quantity orders: We often ship by UPS Air-Express, or DHL/FEDEX/TNT/ EMS Express service. And For large quantity orders: we ship by buyer's cargo agent in China. Also, we can ship by air or sea transportation by our cargo agent.

Delivery Time:

Ready-made Sample: within 1 week

Custom Sample: 1~2 weeks

Mass production: 3-4 weeks



FAQs



1. Do you offer customized service?
-Yes, we offer OEM&ODM service and send us your requirements.

2. What payment methods do you accept?
-We accept via TT/West Union/Paypal.

3.Do you provide samples?

-Yes, we offer sample but you need to pay sample fee and delivery fee.

4. How long does it take to produce the product?
-It depends on the product you need. Different needs determine the production time

5. What's the process for placing an order?
-PO is placed by clients → PI is issued by Royal Display → Payment by clients → Lead time is confirmed by Royal Display → Shipping instrction by Clients → Delivery → Cargo tracking → Receipt of cargo
