Active Area: | 211.2*158.4 Mm | Bezel Opening Area: | 214.8*162.7 Mm |
---|---|---|---|
Module Power Consumption: | 4.1w | Weight: | 505g |
Operating Temp: | -30 To +85 Celsius Degree | Contrast Ratio: | 700 |
High Light: | 800*600 10.4'' TFT LCD,RGB LCD 10.4'' TFT LCD,INNOLUX G104AGE-L02 |
10.4'' TFT LCD INNOLUX G104AGE-L02 800*600 RGB wide view wide temperature display
Product Description
The Innolux G104AGE-L02 is a 10.4-inch TFT LCD (Thin-Film Transistor Liquid Crystal Display) panel produced by Innolux Corporation. It is commonly used in various industrial applications, such as medical devices, automotive displays, point-of-sale systems, and other embedded systems that require a compact display with good image quality.
Here are some key specifications of the Innolux G104AGE-L02:
Item | STANDARD Value |
LCD size | 10.4 inch(Diagonal) |
Driver element | a-Si TFT active matrix |
Resolution | 800 x R.G.B. x 600 |
Display mode | Normally white |
Pixel Pitch | 0.264*0.264 mm |
Active area | 211.2* 158.4 mm |
Contrast Ratio | 700:1 |
Pixel Arrangement | RGB vertical Stripe |
Display Colors | 16.2M |
Interface | LVDS |
Surface Treatment | Anti glare, hard coating 3H |
Top & Tst | -30˚C ~ +85˚C &-30˚C-~+85˚C |
Applications
The 10.4'' TFT LCD Innolux G104AGE-L02 panel is commonly used in various industrial applications. Some of the typical applications include:
Medical Devices: The display is suitable for medical equipment such as patient monitoring systems, ultrasound machines, medical imaging devices, and portable medical devices where a compact and high-quality display is required.
Automotive Displays: The panel can be used in automotive applications, including in-car infotainment systems, rear-seat entertainment displays, and instrument clusters.
Industrial Control Systems: The display is well-suited for industrial control panels, human-machine interfaces (HMIs), factory automation systems, and process control displays.
Point-of-Sale (POS) Systems: The panel can be integrated into point-of-sale terminals, cash registers, self-service kiosks, and other retail and hospitality applications.
Gaming Machines: It can be used in gaming machines, casino displays, and amusement equipment that require small-sized displays with good image quality.
Public Information Displays: The display can be utilized in public information displays, interactive kiosks, and digital signage applications for information dissemination in public spaces.
Embedded Systems: The panel is suitable for various embedded systems where a compact and reliable display solution is needed, such as industrial equipment, measurement devices, and control panels.
These are just a few examples of the applications where the Innolux G104AGE-L02 panel can be employed. Its compact size, good image quality, and compatibility with industrial environments make it a popular choice for a wide range of industrial and embedded display applications.
Our Advantages
1. We specializing in the design, development and production of LCD display module full scheme for more than 10years. Each product undergoes professional design, debugging, production and quality inspection to ensure that the product meets shipping standards.
2. Broad selection of off the shelf products can be chosen and most products are kept in stock and can ship same day.
3. We also offer customed services for you, and can provide drawings and procedures for customers to confirm.
4. Our products offer sunlight readable options , and each display offers capacitive and resistive options
5. We provide reliable warranty service and the warranty preriod is one year.
Packaging & Shipping
Packaging : All the products are packed in right way to keep it safe. For small sizes of products we often use tray + carton, and for bigger sizes we use foam slot + carton. Also we can design packages to meet customers' requirements.
Shipping : For small quantity orders: We often ship by UPS Air-Express, or DHL/FEDEX/TNT/ EMS Express service. And For large quantity orders: we ship by buyer's cargo agent in China. Also, we can ship by air or sea transportation by our cargo agent.
Delivery Time:
Ready-made Sample: within 1 week
Custom Sample: 1~2 weeks
Mass production: 3-4 weeks
