2.4'' IPS LCD Module Free View 240*320 RGB CTP Optical Bonding MIPI 1000:1
Product Details:
| Place of Origin: | CHINA |
| Brand Name: | ROYAL DISPLAY |
| Certification: | SGS, ROHS |
| Model Number: | HXM024HBH17B V1.0 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 100pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Cartons, Capboard, EPE, Blister Tray. |
| Delivery Time: | 15~25 working day |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 300K pcs/month |
|
Detail Information |
|||
| Panel Type: | IPS | LCD Size: | 2.4 Inch |
|---|---|---|---|
| Resolution: | 240*320 RGB | Display Mode: | Normally Black |
| NTSC: | 70% | Contrast Ratio: | 1000:1 |
| TP Type: | CTP/ Optical Bonding | Driver IC: | ST7785M |
| Highlight: | 2.4'' IPS LCD Module,MIPI IPS LCD Module,CTP ips tft lcd display |
||
Product Description
2.4'' IPS LCD module free view 240*320 RGB CTP optical bonding MIPI 1000:1
Product Description
A 2.4 inch IPS LCD module with CTP (Capacitive Touch Panel) and optical bonding refers to a display module that combines several technologies. Let's break down each component:
-
IPS LCD: IPS stands for In-Plane Switching, which is a type of display technology known for its wide viewing angles and accurate color reproduction. The 2.4 inch refers to the diagonal size of the display.
-
CTP: CTP stands for Capacitive Touch Panel, which is a type of touch-sensitive input device that uses the electrical properties of the human body to detect touch. Capacitive touchscreens are known for their responsiveness and multi-touch capabilities.
-
Optical Bonding: Optical bonding is a process that eliminates the air gap between the touch panel and the LCD display by filling it with a transparent adhesive. This bonding process helps to reduce reflections, improve contrast, increase sunlight readability, and enhance overall display clarity.
| ITEM | SPECIFICATION |
| Pixels | 240*320 RGB |
| LCD Type | IPS |
| Active Area | 36.72*48.96 |
| Module size | 84.12(H)*62.00(V)*3.58(D) |
| pixel pitch | 0.153*0.153 mm |
| Driver IC | ST7785M |
| Interface | 1 Lane MIPI |
| light source | 4 white leds |
| Wide range of operating temperature | -20 to +70 ºC |
| Wide range of Storage temperature | -30 to +80 ºC |
Applications
Combining these technologies, a 2.4 inch IPS LCD module with CTP and optical bonding would provide a small-sized, high-quality display with touch functionality. It would be suitable for various applications such as handheld devices, wearables, industrial control systems, and more, where a compact and responsive display is required.
Our Service
1. Best Quality Control : Every LCD tested with special instruments or main boards before delivery to ensure working.
2. Correct Packaging Way: Packed in anti-static bags with foam box to ensure safety in transportation.
3. Multiple Payment Methods: T/ T, Western Union,L/ C, PayPal.
4. Reliable Shipping Methods: Prompt delivery by UPS, EMS, DHL, TNT, or by air.
5. Professional Customized Service: Professional team provide OEM&ODM service.
6. Competitive Price: Give you a direct factory price.
7. Better After-sales Service: Long for one year warranty.
