| Screen Size: | 3.5" TFT LCD | Resolution: | 320X3(RGB)X240 |
|---|---|---|---|
| Aspect Ratio: | 16:9 | Interface: | 40pin FPC, Parallel 24bit RGB |
| Luminance(nits): | 400 | Contrast Ratio: | 500 |
| Application: | Industrial Application | ||
| Highlight: | Tft Lcd Display Module,Hd Tft Display |
||
3.5 Inch 320X240 Landscape IPS TFT LCD Display Monitor LCM
Descriptions
1. 320 x RGB x 240 dots
2. Innolux TFT Display
3. 0.96-10.1 inch LCD panel & module are available
4. Support OEM & OEM service
5. More than 10years LCD experience
| Item | Description |
| Model Name | AT056TN52 V.3 |
| Product type | LCD Module |
| Screen Size | 3.5" |
| Aspect Ratio | 4:3 |
| Resolution | 320X3(RGB)X240 |
| Module Size(mm) | 126.5 x 100.0 x 5.7 |
| Active Area(mm) | 112.896 x 84.672 |
| Viewing Angle (Tpy.)θT/θB/θL/θR | 50/70/70/70 |
| Luminance(nits) | 200 |
| Contrast Ratio | 500 |
| Response Time(ms) | 25 |
| Interface | 50pin FPC,Parallel 24bit RGB |
| Operation Temperature( ºC) | -20º C~70ºC |
| Storage Temperature (ºC) | -30º C~80ºC |
Application
Our LCD module size are from 2.8 inch to 10.1 inch which are widely used in digital camera, DV, security monitoring, carcorder, PMP, MID and Education Learning Aid, POS Machine etc.
Our Advantage
1) Quality Control: Every LCD tested with special instruments or main boards before delivery to ensure working. Both Original and High quality OEM products available.
2) Packing: Packed in anti-static bags with foam box to ensure safety in transportation.
3) Payment Terms: T/T, Western Union.
4) Service: Best after-sales service to ensure satisfaction from customers.
5) Delivery: Goods will be delivered with 2-4 days by DHL, UPS, TNT, EMS, or By Air
6) Warranty: Usually, product warranty for one year.
7) Samples: Our company offers samples for quality test or other business purposes, but we kindly ask you to pay for samples and the freight.
FAQ
Q: Are you a factory or trading company?
A: We are a OEM/ODM factory.
Q: What is the MOQ?
A: Generally if you choose the different products, our minimum order qty also will be different.
Q: What about the production time?
A: The LCD products need 5-6 weeks to be made after receive deposit.
Q: Do you offer custom solution?
A: Yes,we can offer custom solution if standard products couldn't meet buyer' requirements.
Q: How can I get the samples?
A: If you need samples, we can make as per your request .
You should pay the sample fee and freight. Sample lead time always be within 2-5 days.
Q: How long can I expect to get the sample?
A: The samples will be ready for delivery in 5~7days.The samples will be sent via express and arrive in 5~7 days.
