5.6 Inch 640X480 Innolux LCD Panel VGA Parallel RGB At056tn53 V. 1
Product Details:
| Place of Origin: | China |
| Brand Name: | ROYAL DISPLAY |
| Certification: | ROHS, ISO |
| Model Number: | AT056TN53 V. 1 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 500pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Cartons, Capboard, EPE, Blister Tray |
| Delivery Time: | 15-20 work days |
| Supply Ability: | 300K/M |
|
Detail Information |
|||
| Product Type: | TFT LCD | Resolution: | 640X3(RGB)X480 |
|---|---|---|---|
| Display Mode : | Normally Black, Transmissive | Panel Type: | A-Si TFT-LCD, Panel |
| Touch Panel : | With/Without | Signal Interface: | Parallel RGB (1 CH, 6-Bit), 40 Pins |
| Highlight: | 5.6 Inch Innolux LCD Panel,640X480 Innolux LCD Panel,Parallel RGB TFT LCD Panel |
||
Product Description
AT056TN53 V.1 Innolux LCD Panel 640(RGB)x480 VGA Resolution
Quick Detail Of TFT LCD Module
- Model:AT056TN53 V. 1
- Resolution:640x480
- Panel Size:4.3 inch tft lcd panel
- Panel Type:View All IPS
| Panel Size | 5.6 inch |
|---|---|
| Dot Resolution | 640(RGB)×480 (VGA) |
| Pixel Configuration | RGB Vertical Stripe |
| Pixel Density | 143 PPI |
| Aspect Ratio | 4:3 (H:V) |
| Form Factor | Flat Rectangle Display |
| Dot Pitch | 0.0588×0.1764 mm (H×V) |
| Pixel Pitch | 0.1764×0.1764 mm (H×V) |
| Weight | 83.1g (Typ.) |
| Surface | Antiglare |
| Active Area | 112.896×84.672 mm (H×V) |
| Bezel Area | 115.90×87.67 mm (H×V) |
| Outline Dimension | 126.5×100 mm (H×V) |
| Outline Depth | 5.7±0.3 mm |
| Landscape or Portrait | Landscape type |
| Touch Panel | With/Without |
