Dot Matrix Lcd Graphic Display Module For Electric Power Device 160*160 Dots
Product Details:
| Place of Origin: | CHINA |
| Brand Name: | ROYAL DISPLAY |
| Certification: | SGS ROHS |
| Model Number: | RYD160160A |
Payment & Shipping Terms:
| Minimum Order Quantity: | 500pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | 220pcs/CTN 15Kg L45*W36*H32CM |
| Delivery Time: | 30~35 Working Days |
| Supply Ability: | 500k/Month |
|
Detail Information |
|||
| Product Name: | RYD160160A 160*160 Dots With PCBA COG Graphic LCD Module | Model No.: | RYD160160A |
|---|---|---|---|
| Dot Format: | 160x160 | Viewing Area(mm): | 60.0x60.0 |
| Viewing Angle: | 6 O' Clock | LCD Type: | FSTN-Positive |
| LED Backlight: | White | Driver IC: | UC1698 |
| Operating Temp: | -20º C~70º C | Storage Temp: | -30º C~80º C |
| Highlight: | Lcd Dot Matrix Display,Dot Matrix Lcd Module |
||
Product Description
Dot Matrix RYD160160A 160*160 dots With PCBA COG Graphic LCD Module FSTN Black on White
- COG Graphic LCD Module with PCBA
- Dots Format , 160X160
- Controller , UC1698 OR EQUIV
- STN-Gray, Blue,DFSTN-Negative.FSTN-Postive
- LED Back Light , White , Red , Amber .
- Widely Use On Electric Power Device .
-
CN1 SYMBOL 1 GND 2 AO 3 /WR 4 /RD 5 /CS 6 /RST 7 VCC 8~15 DB0~OB7 16 K 17 NC 18 A
