RYP240160A COG LCD Module FSTN Positve 240*160 Dots White LED Backlight

Name: RYP240160A COG LCD Module FSTN Positve 240*160 Dots White LED Backlight
Brand: ROYAL DISPLAY
SKU: RYP240160A
Rating: 4.9 (149 reviews)

Large Image : RYP240160A COG LCD Module FSTN Positve 240*160 Dots White LED Backlight

Product Details:

Place of Origin:	CHINA
Brand Name:	ROYAL DISPLAY
Certification:	SGS ROHS
Model Number:	RYP240160A

Payment & Shipping Terms:

Minimum Order Quantity:	500pcs
Price:	Negotiable
Packaging Details:	160pcs/CTN 9.5Kg L45W36H32CM
Delivery Time:	25~28 Working Days
Supply Ability:	500k/Month

Contact Now

Detailed Product Description

Product Name:	COG Display 240 X 160( RYP240160A)	Model No.:	RYP240160A
Dot Format:	240x160	Viewing Angle:	6 O' Clock
LCD Type:	FSTN	LED Backlight:	White
Driver IC:	ST7586S	Operating Temp:	-20º C~70º C
Storage Temp:	-30º C~80º C
High Light:	Cog Lcd Display , Tft Lcd Screen

RYP240160A COG LCD Module FSTN Positve 240*160 dots , 3.3V Power supply With PCBA , Completely Replace LM240160SCW

COG LCD Module
Dots Format , 240x160
Controller , ST7586S OR EQUIV
STN-Gray, Blue,DFSTN-Negative.FSTN-Postive
Widely Use On Hand-held Device

PIN	SYMBOL
1	VDD
2	VSS
3	/CS
4	RS
5	/WR
6	/RD
7~14	DB0~DB7
15	/RST
16	BLA

RYP240160A COG LCD Module FSTN Positve 240*160 Dots White LED Backlight 0
