FSTN Mono Graphic LCD Display Module 128X32 Dots Positive Screen

FSTN Mono Graphic LCD Display Module 128X32 Dots Positive Screen
FSTN Mono Graphic LCD Display Module 128X32 Dots Positive Screen FSTN Mono Graphic LCD Display Module 128X32 Dots Positive Screen

Large Image :  FSTN Mono Graphic LCD Display Module 128X32 Dots Positive Screen

Product Details:
Place of Origin: CHINA
Brand Name: ROYAL DISPLAY
Certification: SGS ROHS
Model Number: RYG12832A
Payment & Shipping Terms:
Minimum Order Quantity: 500pcs
Price: Negotiable
Packaging Details: 220pcs/CTN 11Kg L45*W36*H32CM
Delivery Time: 25~28 Working Days
Supply Ability: 300k/Month
Detailed Product Description
Product Name: COG Graphic LCD Module 128*32 Dots Model No.: RYG12832A
Dot Format: 128x32 Viewing Angle: 6 O' Clock
LED Backlight: White Driver IC: ST7586S
Operating Temp: -20º C~70º C LCD Type: DFSTN
High Light:

RYG12832A Mono Graphic LCD Display

,

ST7586S FSTN Graphic LCD Display

,

RYG12832A Positive LCD Screen



Serial Interface Positive FSTN 12832dots Monochrome Custom LCD Display



Mono lcd has been a leading supplier of graphical LCDs for design engineers since 1998. All of our products come with a one year warranty and free product technical support.



General Specifications



1. COG Graphic LCD Module

2. Dots Format, 128x32

3. Controller, ST7567 OR EQUIV

4. STN-Gray, Blue, DFSTN-Negative, FSTN-Postive

5. LED Back Light, White, Red, Amber

6. Widely Use On Hand-held Device

Item Description
Product Name 128x32 dots Graphic LCD Module
Model No.
Dot Format 128X32
Viewing Angle 6 O' clock
LCD Type FSTN-Positive, STN-Gray
Backlight White or Amber LED backlight
Driver IC ST7567
Power supply 3.3V
Interface Parallel
Operating Temp -30º C~70ºC
Storage Temp -30º C~80ºC

RYG12832A
FSTN Mono Graphic LCD Display Module 128X32 Dots Positive Screen 0

FSTN Mono Graphic LCD Display Module 128X32 Dots Positive Screen 1

Typical Applications

Clusters, Car Radios, Air conditioner, Home Automation, Industrial Instruments, etc

Features

Transmissive, Transflective and Reflective Mode

Duty Ratio: up to 1:240

support gray scale display

Wide Operation & Storage temperature range

FAQ


Q1. How can I get the samples?



A: If you need samples, we can make as per your request .You should pay the sample fee and freight. Sample lead time always be within 2-5 days.



Q2. How to order lcd?



A: Please send us your purchase order by Email, or ask us to send you one invoice. We need to know the following information for your order.



1) Product information-Quantity, part number



2) Delivery time required.



3) Shipping information-Company name, Street address,Phone&Fax number,Destination sea port.



4) Forwarder's contact details if you have any in China.





Q3. When can I get the datasheet?



A: When we get your inquiry, you shall first tell us the part number you want, then we can send you the datasheet immediately



Q4. How long can I expect to get the sample?



A: The samples will be ready for delivery in 5~7days.The samples will be sent via express and arrive in 5~7 days.



Custom LCD/LCM are available



We take your positive feedbacks and high DSRs as our life, it is the important thing for us. If you can't get the item at that time or the item is not as good as you expected, then pls feel free to contact us, we'll try our best to fix this problem asap.
