Common Anode Full Muti color20mA SMD RGB LED Segment Display Graphics

Large Image : Common Anode Full Muti color20mA SMD RGB LED Segment Display Graphics

Product Details:

Place of Origin:	China
Brand Name:	ROYAL DISPLAY
Certification:	ROHS, ISO
Model Number:	RYS5233W

Payment & Shipping Terms:

Minimum Order Quantity:	1000pcs
Price:	Negotiable
Packaging Details:	Cartons, Capboard, EPE, Blister Tray
Delivery Time:	15~25 working days
Payment Terms:	MoneyGram, Western Union, T/T, L/C, D/P, D/A
Supply Ability:	1000K pieces/Month

Contact Now

Detailed Product Description

Size:	0.28''~4''	Tube Chip Color:	Full Color
Display Function:	Graphics	Pixels:	10mm
Surface Color:	Black Or Grey Color	Polarity:	Common Anode
Digits:	1 To 6	Color:	Red, Green, Blue, Yellow, Orange...
Highlight:	SMD RGB LED Segment Display , 20mA LED Segment Display , Graphics Common Anode Segment Display

Detail Information
Size:	0.28''~4''	Tube Chip Color:	Full Color
Display Function:	Graphics	Pixels:	10mm
Surface Color:	Black Or Grey Color	Polarity:	Common Anode
Digits:	1 To 6	Color:	Red, Green, Blue, Yellow,

Product Description

Size	Digit	Digit Height	Polarity	Color	Face
0.28" LED DISPLAY	one	7.0mm	CC/CA	R,G,B,Y,W	Black/Grey
0.3" LED DISPLAY	one	7.8mm	CC/CA	R,G,B,Y,W	Black/Grey
0.36" LED DISPLAY	one	9.1mm	CC/CA	R,G,B,Y,W	Black/Grey
0.39" LED DISPLAY	one	9.9mm	CC/CA	R,G,B,Y,W	Black/Grey
0.56" LED DISPLAY	one	14.2mm	CC/CA	R,G,B,Y,W	Black/Grey
0.8" LED DISPLAY	one	20.4mm	CC/CA	R,G,B,Y,W	Black/Grey
1.2" LED DISPLAY	one	30.6mm	CC/CA	R,G,B,Y,W	Black/Grey
1.5" LED DISPLAY	one	38.1mm	CC/CA	R,G,B,Y,W	Black/Grey
2.3" LED DISPLAY	one	56.8mm	CC/CA	R,G,B,Y,W	Black/Grey
3.0" LED DISPLAY	one	75.0mm	CC/CA	R,G,B,Y,W	Black/Grey
4.0" LED DISPLAY	one	101.6mm	CC/CA	R,G,B,Y,W	Black/Grey

PRODUCT DESCRIPTION

Feature
1. Low power consumption

2. High brightness

3. Easy assembly

4. High intensity and reliability

Parameters
Emitted color	various
Emitted source	chips
Luminance	75 mcd
DC Forward Voltage	2.6-3.6 v
Suggestion Forward Current	20mA
Operating Temperature	-25℃~+85℃

Common Anode Full Muti color20mA SMD RGB LED Segment Display Graphics 0

SHIPPING WAY&PAYING WAY

Common Anode Full Muti color20mA SMD RGB LED Segment Display Graphics 1

LED professional manufacturer ROYAL DISPLAY with over 10 years experience in led field,

we do believe we can become your reliable supplier!
