Smd 7 Segment 0.28'' Common Anode Single Digit Led Display ROHS With Film
Product Details:
| Place of Origin: | China |
| Brand Name: | ROYAL DISPLAY |
| Certification: | ROHS, ISO |
| Model Number: | RYS5227W |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1000pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Cartons, Capboard, EPE, Blister Tray |
| Delivery Time: | 15~25 working days |
| Supply Ability: | 1000K pieces/Month |
|
Detail Information |
|||
| Size: | 0.28''~4'' | Tube Chip Color: | Full Color |
|---|---|---|---|
| Display Function: | Graphics | Pixels: | 10mm |
| Surface Color: | Black Or Grey Color | Polarity: | Common Anode |
| Digits: | 1 To 6 | Color: | Red, Green, Blue, Yellow, Orange... |
| Highlight: | Smd Single Digit Led Display,0.28'' Single Digit Led Display,ROHS 7 Segment Led Display |
||
Product Description
| Size: | Tube Chip Color: |
|---|---|
| Display Function: | Pixels: |
| Surface Color: | Polarity: |
| Digits: | Color: |
Color Code & Chip characteristic PER CHIP: (Test Condition: IF=10-15Ma)
|
Emitting Color |
Test Condition |
Wavelength(nm) | Forward Voltage(V) | Luminous Intensity (mcd) | |||
| (λp) | λ | Typ | Max | Typ | Max | ||
| Amber | IF=10-15mA | 600-605 | 30 | 1.9 | 2.0 | 90 | 100 |
| Super green | IF=10-15mA | 565-575 | 30 | 1.9 | 2.0 | 48 | 55 |
| Super red | IF=10-15mA | 620-625 | 20 | 1.8 | 2.0 | 110 | 130 |
| Ultra red 1 | IF=10-15mA | 620-625 | 20 | 1.8 | 2.0 | 200 | 210 |
| Ultra red 2 | IF=10-15mA | 620-625 | 20 | 1.8 | 2.0 | 300 | 350 |
| High red | IF=10-15mA | 638-660 | 20 | 1.8 | 1.9 | 15 | 20 |
| Yellow green | IF=10-15mA | 570-580 | 30 | 1.9 | 2.0 | 43 | 50 |
| Yellow | IF=10-15mA | 580-600 | 35 | 1.9 | 2.0 | 70 | 80 |
| Blue | IF=10-15mA | 465-475 | 40 | 2.95 | 3.0 | 150 | 200 |
| Pure green | IF=10-15mA | 515-525 | 40 | 2.95 | 3.0 | 180 | 250 |
| White | IF=10-15mA | - | - | 2.8 | 2.9 | 180 | 200 |
Features:
1. Available in 4 and 6 digit formats
2. LED Colors Available: Red, Amber, Green, Blue, White
3. 100,000+ hour rated LEDs available from 4” to 48” tall
4. 8 levels of automatic brightness control
5. Automatic daylight savings adjustments
6. Multiple stroke digits for the ultimate brightness in daylight viewing
7. Time displays in 12 and/or 24 hour format
8. Temperature displays in Fahrenheit or Celsius
9. Display Duration: 3-seconds to 9-seconds
10. LED Viewing Angle: >100°
11. Operating Voltage: 120AC/240AC/12DC/24DC
12. The operating temperature of environment:-20°C - + 55°C
13. There are two kinds of remote control, IR Remote and wireless RF Remote controller.
Our defaulted control is IR Remote for Semi-outdoor signs, RF Remote for Outdoor signs.
a) IR remote controller control distance : 10m
Custom Display
FAQ
Q: Can I get samples before I order?
A: Yes, we can have samples sent to you within 7 working days upon receipt of your payment for these samples.
Q: Do you also customize the products?
A: Yes, we also customize the products according to your requirements.
Q: Can we visit your factory?
A: You are welcome to visit us.
Q: Can I have a sample order?
A: Yes. We warmly welcome the sample for you to test the quality.
Q: Where can l get the datasheet ?
A: When we get your inquiry, and tell us which one you need,we would send you immediately.
Q: How much the transportation freight of the sample?
A: The freight depends on total weight and your address.
Q:What's the delivery time?
A: > For samples order, 2-3weeks;
> For mass orders,4-6weeks.
