128*16 Dots FSTN Customized LCD Module 6H With ST7565P Wide Temperature For UPS Photovoltaic Inverter

128*16 Dots FSTN Customized LCD Module 6H With ST7565P Wide Temperature For UPS Photovoltaic Inverter
128*16 Dots FSTN Customized LCD Module 6H With ST7565P Wide Temperature For UPS Photovoltaic Inverter 128*16 Dots FSTN Customized LCD Module 6H With ST7565P Wide Temperature For UPS Photovoltaic Inverter 128*16 Dots FSTN Customized LCD Module 6H With ST7565P Wide Temperature For UPS Photovoltaic Inverter 128*16 Dots FSTN Customized LCD Module 6H With ST7565P Wide Temperature For UPS Photovoltaic Inverter 128*16 Dots FSTN Customized LCD Module 6H With ST7565P Wide Temperature For UPS Photovoltaic Inverter

Large Image :  128*16 Dots FSTN Customized LCD Module 6H With ST7565P Wide Temperature For UPS Photovoltaic Inverter

Product Details:
Place of Origin: CHINA
Brand Name: Royal Display
Certification: SGS, ROHS
Model Number: RYP7032A-NFTWWN-01-B
Payment & Shipping Terms:
Minimum Order Quantity: negotiable
Price: Negotiable
Packaging Details: Cartons, Capboard, EPE, Blister Tray.
Delivery Time: 15~25 working day
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 300K pcs/month
Detailed Product Description
Display Type: FSTN, Positive Polarizer Mode: Transflective, Anti-UV
Driving Method: 1/65 Duty, 1/9 Bias Operating Temp: -20 To +70 Celsius Degree
Control IC: ST7565P Outline Dimension: 119*84*12.1 Mm
Highlight:

ST7565P FSTN LCD Module

,

6H FSTN LCD Module

,

128*16 dots FSTN LCD Module

128*16 dots FSTN customized LCD Module 6H with ST7565P wide temperature for UPS Photovoltaic Inverter





Product Description



Item Description
Model No. RYP7032A-NFTWWN-01
Module Size(mm) 119.00(L)X84.00(W)X12.10(T)
Viewing Area(mm) 83.00(L)X61.50(W)
Driver Method 1/65 duty 1/9bias
VDD 3.3V
VOP 10.5V
Driver IC ST7565P
Connector Pin
Operating Temp -20º C~70ºC
Storage Temp -30º C~80ºC

128*16 Dots FSTN Customized LCD Module 6H With ST7565P Wide Temperature For UPS Photovoltaic Inverter 0



Our Advantages



1. Quality Control: Every LCD tested with special instruments or main boards before delivery to ensure working. Both Original and High quality OEM products available.

2. Packing: Packed in anti-static bags with foam box to ensure safety in transportation.

3. Payment Terms: T/T, Western Union.

4. Shipping Methods: Prompt delivery by UPS, EMS, DHL, TNT, or by air.

5. Service: Best after-sales service to ensure satisfaction from customers.

6. Delivery: Goods will be delivered with 2-4 days by DHL, UPS, TNT, EMS, or By Air

7. Warranty: Usually, product warranty for one year.

8. Samples: Our company offers samples for quality test or other business purposes, but we kindly ask you to pay for samples and the freight.




Company Profile



Royal Display Co., Ltd has been specializing in LCD business for more than 10 years, products range LCD Display, LCD Screen, LCD Module, Character LCD, LED backlight display, TFT display, Graphic LCD, 7 segment LED Display.

More than 90% of our products is specially customer designed to be used in Video and Audio system, financial, medical, industry equipment, testing devices, Electronic meters, facsimiles, many kinds of terminal equipment and so on. With the capability of 300K different kinds of LCM/LCD per month.





FAQ



1. Q: Can we customize product? What cost will be included?
A: Yes, kindly share your detailed requirements, we will check and review back to you.

2. Q: What is your delivery method?
A: EXW ShenZhen by DHL/ UPS / FEDEX/TNT , or ship the goods to your HK/SZ forwarder.

3. Q: What kind of packaging? The transport process will not be damaged?
A: Our products are divided into two categories, small - medium size use knife card isolation packaging, large size screens are used in aircraft box packaging, all packages are protected by outer box and strapping to ensure the safety of material transportation.

4. Q: How to control the quality of products?
A: The company has a professional quality team, and all products are 100% inspected before shipment.

5. Q: How long is the warranty and service of the product?
A: Generally the warranty period is one year. It depends on different products.We guarantee our products to be free from manufacturer defects. Liability under this warranty is limited to the replacing of any product found to be defective under normal use.
