Ar AG Af Coating 4.3′ ′ TFT LCD Display Coverglass 480X272 LCD Display
Product Details:
| Place of Origin: | China |
| Brand Name: | Royal Display |
| Certification: | SGS ROHS |
| Model Number: | CTP-RYT043F001 |
Payment & Shipping Terms:
| Minimum Order Quantity: | Negotiable |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Cartons, Capboard, EPE, Blister Tray |
| Delivery Time: | 25~28 Working Days |
| Payment Terms: | Western Union, MoneyGram, T/T, D/P, D/A, L/C |
| Supply Ability: | 100k/M |
|
Detail Information |
|||
| Display Type: | P'cap, P'cap | Transmittance: | 85% |
|---|---|---|---|
| Sensor Glass: | 0.55mm | Voltage: | 2.8-3.3V |
| Aspect Ratio: | 16:9 | ||
| Highlight: | AG Af Coating LCD Touch Panel,480X272 LCD Touch Panel,0.55mm LCD Touch Panel |
||
Product Description
AR AG AF Coating 4.3'' TFT LCD Display Coverglass 480x272 LCD Display
Specification Of 4.3 Inch TFT Coverglass
we have standard one and also available to make the customization of with different size, shape, color, logo etc.
Having G+G, G+F, G+F+F Structure. OCA and OCR Optical Bonding.
Cover lens can add AR, AF,AG coating. Driver can be used FT, GT, Atmel, ILITEK, ST...
|
Item
|
Specification
|
|
Display Mode
|
Capacitive touch screen
|
|
Part NO.
|
CTP-RYT043F001
|
|
Resolution
|
480x272
|
|
Outline Size
|
123.04x84.46x1.43mm
|
|
Active Area(WxH)
|
122.44x83.86mm
|
|
Cover glass
|
0.7mm
|
|
Sensor glass
|
0.55mm
|
|
Surface Hardness
|
6H
|
|
Operating Voltage
|
2.8-3.3V
|
|
Operating Temperature
|
-20ºC~70ºC
|
|
Storage Temperature
|
-30ºC~80ºC
|
Warranty
Royal Display offers the original purchaser who has purchased a product from the lcd module tft a limited warranty that the product (including accessories in the product's package) will be free from defects in material or workmanship.
Application
About US
Royal Display Co., Ltd has been specializing in LCD business for more than 10 years, products range LCD Display, LCD Screen, LCD Module, Character LCD, LED backlight display, TFT display, Graphic LCD, 7 segment LED Display.
More than 90% of our products is specially customer designed to be used in Video and Audio system, financial, medical, industry equipment, testing devices, Electronic meters, facsimiles, many kinds of terminal equipment and so on. With the capability of 300K different kinds of LCM/LCD per month.
