0.91 Inch 128x32 I2C IIC Serial Blue 0.91'' OLED LCD Display Module SSD1306 Driver
Product Details:
| Place of Origin: | China |
| Brand Name: | Royal Diaplay |
| Certification: | ISO Rohs |
| Model Number: | RYOM-091-01 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Plastic Tray+Anti-Static Foam+Paper Card+Vacuum Ba |
| Delivery Time: | 20-28 work days |
| Payment Terms: | Western Union, L/C, T/T |
| Supply Ability: | 30K/M |
|
Detail Information |
|||
| Resolution: | 128X32 | Display: | OLED(Yellow/ Blue/ White/ Orange ) |
|---|---|---|---|
| Module Size (mm): | 38x12x2.6 | Display Area(mm): | 22.38x5.584 |
| Driver IC: | SSD1306 | Interface: | IIC Interface |
| Highlight: | IIC Blue OLED LCD Display Module,0.91'' OLED LCD Display Module,SSD1306 Driver OLED Display Module |
||
Product Description
0.91 Inch 128x32 I2C IIC Serial Blue 0.91'' OLED LCD Display Module SSD1306 Driver
Specification Of 0.91 Inch 128x32 Dots OLED Module
| Item | Description |
| Diagonal Screen Size | 0.91 inch |
| Color | Mono(White) |
| Model number | GME12832-11 |
| Resolutions | 128x32 |
| Outline dimension | 38×12×2.6mm |
| Active area | 22.38×5.584mm |
| Pixel pitch | 0.175×0.175mm |
| Pixel size | 0.159×0.159mm |
| Driver IC | SSD1306 |
| Voltage | 3-5V |
| Interface | IIC |
| Operating temperature | -40~85℃ |
| Storge Temperature | -40~85℃ |
| Assemble | Soldering |
| Pins | 4P |
Similar OLED Display
OLED Display Application
Our OLED Displays are widely used at consumer and industrial applications such as Audio, Automotive control panels, Medical devices, White goods or Home automation products, Smart Watch, Smart Bracelet, Device, Equipment, Printer, Projector, Scanner, Fax Machine, Copier, Bar Code Printer and etc.
0.91 Inch Monochrome OLED Module Service Advantages
1. Small order would be accepted.
2. Mass production lead time would be guaranteed.
3. Each order will have 0.2% - 0.5% spare.
4. Even customers do not have a cooperation with us, we also can provide technical services.
5. If mass production has any quality problem, customer can return it.
