| Product Name: | 4X20 VFD LCD Module | Model No.: | RY20S401DA1 |
|---|---|---|---|
| Display Format: | 2x40dots | Viewing Angle: | 6 O' Clock |
| LED Backlight: | White Y/G | Controller: | ST7065 |
| Operating Temp: | -20º C~70º C | LCD Type: | FSTN Postive |
| High Light: | 4X20 Vacuum Fluorescent LCD Display,20S401DA2 Vacuum Fluorescent LCD Display,DOT Matrix VFD LCD Module |
||
New Original LCD 20S401DA2 4X20 Vacuum Fluorescent Display DOT Matrix VFD LCD Module
DISPLAY SPECIFICATION
1. SCOPE
This specification applies to VFD module (Model No: 20S401DA1) manufactured by SSVD (Shanghai Samsung V acuum
Devices)
2. FEATURES
* Vacuum Fluorescent Display: Self Luminous, High Quality and Readable Display
* +5VDC Single Power Supply: Built in DC/DC Converter
* Both Parallel and Serial Interface: Baud-rate: 300 ~ 19,200 bps, Parity Selectable (non, even, odd)
* Two kinds of CG- ROM Font: ASCII + Japanese and ASCII + European
* 4 Brightness Level: 25%, 50%, 75% and 100%
* Character Format: 5*7 Dot Matrix
| Item | Description |
| Product Name | 4X20dots VFD LCD Module |
| Model No. | RY20S401DA1 |
| Dot Format | 4x20 |
| Outline (mm) | 150.0* 64.0 * 28.6 |
| Glass Size(mm) | 118.2 *48.3 |
| Display Area( mm) | 89. 52 * 33.07 |
| Character Format | 5 * 7 Dot Matrix |
| Number of Digits | 80 (4 lines * 20 characters) |
| Backlight | LED backlight |
| Power supply | 5V |
WHAT'S VFD MODULE
A VFD module incorporates a controller, anode driver, grid driver and power supply circuit to make evaluation easy.
Perform a variety of display control functions using a simple command. Multiple interface options are available.
To accomodate customer specifications, we can do special orders for interface and software.
The CU-U series displays are all built with LCD compatible dimensions and HD44780 command sets. These displays are easy to read due to high contrast, have wide viewing angles and are easier to read at short and long distances. Additionally, VFD displays have a quick display response within the module’s temperature range of -40C to +85C. Noritake offers long term supply and engineering support with their products.
