Customized 128*32DOTS IC ST7921 Capacitive with white LED backlight Graphic LCD Module 128x32 Dots For Electronic Scale
Product Details:
| Place of Origin: | China |
| Brand Name: | ROYAL DISPLAY |
| Certification: | ROHS, ISO |
| Model Number: | RYP12832A |
Payment & Shipping Terms:
| Minimum Order Quantity: | 500pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Cartons, Capboard, EPE, Blister Tray |
| Delivery Time: | 15-20 work days |
| Supply Ability: | 300K/M |
|
Detail Information |
|||
| Product Name: | 128x32dots LCD Module | Model No.: | RYP12832A |
|---|---|---|---|
| Dot Format: | 128*32 | Outline (mm): | 119.0*58.0*11.7 |
| Viewing Angle: | 6 O' Clock | LCD Type: | FSTN-Positive, STN-Gray |
| Backlight: | White Backlight | Driver IC: | ST7921 |
| Power Supply: | 5V | Interface: | Parallel |
| Storage Temp.: | -20°C~+70°C | Operating Temp.: | 0°C~+50°C |
| Highlight: | FSTN ST7921 Graphic LCD Module,IC ST7921 Capacitive Graphic LCD Module,128x32 FSTN LCD Monitor Module |
||
Product Description
128x32 Dots Drive IC ST7921 Capacitive Graphic LCD Module
PRODUCT DESCRIPTION
1. 128x32dots
2. Parallel interface
3. Ultra high contrast, YG & White LED backlight as option
4. STN-YG, STN-blue, STN-Gray, FSTN-Positive display results as option
| Item | Description |
| Product Name | 128x32 dots LCD Module |
| Model No. | RYP12832A |
| Dot Format | 128x32 dots |
| Outline (mm) | 119.0*58.0*11.7 |
| LCD Type | FSTN-Positive, STN-Gray |
| Dot Pitch(WXH) |
0.57 X0.5
|
| Viewing Angle | 6 O' clock |
| LCD Type | FSTN-Positive, STN-Gray |
| Backlight | White |
| Driver IC | ST7921 |
| Power supply | 5V |
| Interface | Parallel |
| Operating Temp | -30º C~70ºC |
| Storage Temp | -30º C~80ºC |
OUR ADVANTAGES
1. More than 10 years experience, strong background in Monochrome LCD display design.
2. IATF16949:2016 and ISO9001:2015 certificated manufacture, provided all customized solutions.
3. Faster support in Front and After-sales services. Support customer from the product design.
CUSTOMER PRAISES
APPLICATIONS
Our products can be widely used in telecommunication devices, consumer products, telecommunication devices, technical equipment, office automation, home appliances, automobile, it products, medical equipment and other fields.
