| Product Name: | 16x2 Character LCD Module | Model No.: | RYP1602A-8 |
|---|---|---|---|
| Dot Matrix / Resolution: | 5×8 Dots Includes Cursor | Characters × Lines: | 16 Characters × 2 Lines |
| Module Dimension: | 80.0 × 36.0 × 13.5 (MAX) | Viewing Area: | 66.0 × 16.0 |
| IC: | ST7066 Or Equivalent, Option RW1063 | Interface: | 6800, Option SPI / I2C (RW1063 IC) |
| Power Supply: | 5V (Also Aviailable For 3V) Negative Voltage Optional For 3V Power Supply | Duty: | 1/16 Duty Cycle |
| Type: | Character LCD Display | Feature: | LED Can Be Driven By PIN1, PIN2, PIN15, PIN16 Or A And K |
| High Light: | 1602 Character LCD Display,16x2 Character LCD Module,STN Blue alphanumeric lcd display |
||
1602 Character LCD Display Monochrome STN Blue Alphanumeric LCD 16X2
Quick Detail of 1602 LCD module
RYP1602A LCD Display Module 16 Character x 2 Lines with LED backlight provides various color combinations for backlight, for example, yellow-green, blue, white, amber, red. This LCD module without backlight is also available.
Default power supply is 5V (3V is optional). Negative voltage is an available option for 3V module. The difference between RC1602B and RC1602B1 is the position of pins. Pins of RC1602B is at the top; Pins of RC1602B1 is at the bottom. LED can be driven by PIN1, PIN2, PIN15, PIN16 or A and K.
Specification of 1602 Character LCD display
| Item | Description |
| Product Name | 16x2 COB LCD Module |
| Model No. | RYP1602A |
| Dot Format | 16 x 2 |
| Outline Dimension(mm) | 80.0 x 36.0MAX |
| Assem. Size(mm) | 75.0 x 31.0 |
| Viewing Area(mm) | 64.6 x 16.0 |
| Character Size( mm) | 2.95 x 5.55 |
| Viewing Angle | 6 O' clock |
| LCD Type | STN-YG |
| Backlight | Yellow Green |
| Driver IC | AIP31066 |
| Power supply | 3.3V or 5V |
| Interface | Parallel |
| Operating Temp | -20º C~70º C |
| Storage Temp | -30º C~80º C |
Contour Drawing of 16x2 Monochrome LCD display
Features of Character LCD display/Alphanumeric LCD
The standard character display resolution includes 8x2, 12x2, 16x1, 16x2, 16x4, 20x2, 20x4, 24x2, 40x2, 40x4 character LCD display. Character LCD modules are available in COB and COG types with different interfaces in 8080,SPI,I2C.LCD character display modules are in STN/FSTN/FFSTN LCD displays with different LED backlight in Yellow-Green, White and Blue color. The character module font options are English/Japanese, European, eastern European, Scandinavian European, Cyrillic (Russian), and Hebrew/Arabic. We offer character displays with 5V operating voltage as standard and 3V or 3.6V options are also available by request.
1. We are professional LCD module manufacture in China with precise and advanced equipments.
2. High quality Control with CE,ROHS and so on approved.
3. More than 10 years of industry experience and involved main markets all over the world
4. Dedicated and professional sales team will offer you 24 hours online and immediate service
5. OEM and ODM support,12 months warranty for all of our products
6. Our mission is to help our customers achieve success, then fulfill our both dreams
