RYG128128A Graphic LCD Module Monochrome Stn Gray 128x128 FPC
Product Details:
| Place of Origin: | CHINA |
| Brand Name: | ROYAL DISPLAY |
| Certification: | SGS ROHS |
| Model Number: | RYG128128A |
Payment & Shipping Terms:
| Minimum Order Quantity: | 500pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | 220pcs/CTN 11Kg L45*W36*H32CM, Cartons, Capboard, EPE, Blister Tray |
| Delivery Time: | 25~28 Working Days |
| Payment Terms: | L/C, T/T, , L/C, Western Union, MoneyGram |
| Supply Ability: | 10K/Month |
|
Detail Information |
|||
| Product Name: | Stn Gray 128*128 Graphic LCD Module | Model No.: | RYG128128A |
|---|---|---|---|
| Display Format: | 128x128dots | LCD Type: | STN Gray, Transflective, Positive |
| Viewing Angle: | 6 O' Clock | Controller IC: | St7541(Cog) |
| Connector: | FPC | Operating Temp.: | -20º C~70º C |
| Storage Temp.: | -30º C~80º C | ||
| Highlight: | Monochrome Stn Graphic LCD Module,RYG128128A Graphic LCD Module,FPC 128x128 LCD Module |
||
Product Description
Customized Stn Gray 128*128 Graphic LCD Module RYG128128A
Display Specifications
| Item | Description |
| Model No. | RYG128128A |
| Display Type | STN Gray, transflective, positive |
| Outline (mm) | 76.5*76.2mm |
| Viewing Angle | 6 O' clock |
| Driver method | 1/128duty 1/12bias |
| Operating Voltage | 3.0V |
| Connector | FPC |
| Operating Temp | -20º C~70ºC |
| Storage Temp | -30º C~80ºC |
Typical Applications
Clusters, Car Radios, Air conditioner, Home Automation, Industrial Instruments, etc
Graphic LCDs
Graphic LCDs can display fully changeable graphics. It is a common option for applications that need to display many different menus or need the ability to display several different fonts and font sizes. In addition to the changing graphics, it also can provide optimal sunlight readability with low power consumption.
Features
Wide variety of off the shelf sizes and resolutions
Most products kept in stock and can ship same day
Ability to display fully changeable graphics
Sunlight readable
Low power consumption
Fully customizable
Custom LCD/LCM are available
