100% Replace Wdn0379-Tmi-#01 Stn Blue Segment Graphic LCD Module
Product Details:
| Place of Origin: | CHINA |
| Brand Name: | ROYAL DISPLAY |
| Certification: | ROHS |
| Model Number: | RYP7047A |
Payment & Shipping Terms:
| Minimum Order Quantity: | 500pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Cartons, Capboard, EPE, Blister Tray. |
| Delivery Time: | 25~28 Working Days |
| Payment Terms: | L/C, T/T, Western Union, MoneyGram |
| Supply Ability: | 20K/Month |
|
Detail Information |
|||
| Product Name: | Graphic STN Blue Monochrome LCM Display Module With Backlight | Display Type: | STN Blue, Transmissive, Negative |
|---|---|---|---|
| Type: | Graphic COB | Driver Method: | 1/3bias, 1/4duty |
| Viewing Direction: | 6 O'clck | IC: | HT1621*2 |
| Backlight: | LED White | Voltage: | LCD=4.5V, LCM=5V |
| Operating Temp.: | -20℃~+70℃ | Stroage Temp.: | -30℃~+80℃ |
| Customized: | Available,OEM ODM Welcome | ||
| Highlight: | Stn Graphic LCD Graphic Module,ROHS FSTN Graphic LCD Module,FPC FSTN Lcd Display Module |
||
Product Description
100% Replace Wdn0379-Tmi-#01 Stn Blue Segment Graphic LCD Module
PRODUCT DESCRIPTION
Specification
1. LCD Display Type: STN BLUE
2. Polarzier Mode: Transmissive, Negative
3. Viewing Direction: 6:00
4. Drive Method: 1/3Bias,1/4Duty
4. Drive Method: 1/3Bias,1/4Duty
5. Driving Voltage: LCD=4.5V LCM=5.0V
6. Operating Temp: -20 TO 70ºC
7. Storage Temp: -30 TO 80ºC
8. IC: HT1621*2
9. Connector: LCD+PCB+LED
10. LED Backlight: white Vf=5.0V If1=98mA If2=26mA
6. Operating Temp: -20 TO 70ºC
7. Storage Temp: -30 TO 80ºC
8. IC: HT1621*2
9. Connector: LCD+PCB+LED
10. LED Backlight: white Vf=5.0V If1=98mA If2=26mA
| Item | Description |
| Product Name | 240x128 LCD Module |
| Model No. | RYP240128A |
| Dot Format | 240x128 |
| Outline (mm) | 188.0 x 148.0 x 7.9 |
| Active Area(mm) | 120.22 x 60.0 |
| Display Mode | STN Blue |
| Duty | 1/3Bias,1/4Duty |
| Driver IC | HT1621*2 |
| Viewing Direction | 6:00 |
| Operating Temp | -20º C~70ºC |
| Storage Temp | -30º C~80ºC |
