STN Type 192x64 Resolution Graphic LCD Module Yellow + Green Color 19264 Dots

STN Type 192x64 Resolution Graphic LCD Module Yellow + Green Color 19264 Dots
STN Type 192x64 Resolution Graphic LCD Module Yellow + Green Color 19264 Dots STN Type 192x64 Resolution Graphic LCD Module Yellow + Green Color 19264 Dots

Large Image :  STN Type 192x64 Resolution Graphic LCD Module Yellow + Green Color 19264 Dots

Product Details:
Place of Origin: CHINA
Brand Name: ROYAL DISPLAY
Certification: SGS ROHS
Model Number: RYP19264A
Payment & Shipping Terms:
Minimum Order Quantity: 500pcs
Price: Negotiable
Packaging Details: 220pcs/CTN 11Kg L45*W36*H32CM
Delivery Time: 25~28 Working Days
Payment Terms: D/A, L/C, , D/P, T/T, Western Union, MoneyGram
Supply Ability: 10k/Month
Detailed Product Description
Product Name: Industrial Application 19264 Graphic COB LCD Module RYP19264A Model No.: RYP19264A
Dot Format: 192X64 LCD Type: FSTN Postive
Viewing Angle: 6 O' Clock LED Backlight: White Y/G
Controller: S6B0108 Operating Temp: -20º C~70º C
High Light:

Lcd Graphic Display Module

,

Monochrome Graphic Display



STN Type 192x64 resolution lcd display yellow+green color graphic 19264 dots LCD module



General Specifications



1. 192x64 dots
2. Parallel interface
3. DC/DC on board, 5V power supply
4. Ultra high contrast, YG & White LED backlight as option
5. STN-YG, STN-blue, STN-Gray, FSTN-Positive display results as option



Display Specifications



 Item  Description
 Product Name  192X64 dots Graphic LCD Module
 Model No.  RYP19264A
 LCD Type  FSTN-Positive, STN-Blue, STN-YG
 Dot Format  192x 64
 Outline Dimension(mm)  130X65
 Assem. Size(mm)  130.0 x 53.0
 Viewing Area(mm)  104.0 x 39.0
 Pixel Size( mm)  0.468 x 0.468
 Viewing Angle  6 O' clock
 Backlight  White or Y/G LED backlight
 Driver IC  S6B0108
 Power supply  3V or 5V
 Interface  Parallel
 Operating Temp  -20º C~70º C
 Storage Temp  -30º C~80º C





STN Type 192x64 Resolution Graphic LCD Module Yellow + Green Color 19264 Dots 0



Typical Applications

Clusters, Car Radios, Air conditioner, Home Automation, Industrial Instruments, etc

Features

Transmissive, Transflective and Reflective Mode

Wide Operation & Storage temperature range

Duty Ratio: up to 1:240

support gray scale display

FAQ


Q1. How can I get the samples?



A: If you need samples, we can make as per your request .You should pay the sample fee and freight. Sample lead time always be within 2-5 days.



Q2. How to order lcd?



A:Please send us your purchase order by Email, or ask us to send you one invoice. We need to know the following information for your order.



1)Product information-Quantity, part number



2)Delivery time required.



3)Shipping information-Company name, Street address,Phone&Fax number,Destination sea port.



4)Forwarder's contact details if you have any in China.



Q3. How long can I expect to get the sample?



A:The samples will be ready for delivery in 5~7days.The samples will be sent via express and arrive in 5~7 days.





Custom LCD/LCM are available
