Graphic 128*64 small Monochrome LCD Module with NT7107/NT7108 6800 interface customizable

Graphic 128*64 small Monochrome LCD Module with NT7107/NT7108 6800 interface customizable

Product Description

A graphic LCD (Liquid Crystal Display) is a type of display that can display graphical content and custom patterns. Unlike character-based LCDs that are limited to displaying predefined characters, a graphic LCD allows you to control individual pixels, enabling you to create custom shapes, images, and graphical user interfaces. A 128x64 graphic LCD module refers to a display panel with a resolution of 128 pixels in width and 64 pixels in height. It is commonly used for displaying graphical content, icons, and text in various electronic devices. Here are some data about a 128 x 64 dots graphic LCD.

Item	Specification
Product Name	128x64 dots Graphic LCD Module
Model No.	Wg12864C
Dot Format	128x64
LCD Display Mode	STN/TN Monochrome, color optional
View Angel	12H or 6H
Driving Method	1/64 Duty
Backlight	WHITE
Drive IC	NT7107/NT7108
Operation Voltage(V)	7.0 v max
LCM technological conditions	RoHS
Operating Temp	-20º C~70ºC
Storage Temp	-30º C~80ºC

Product Features

A 128x64 dots graphic LCD module offers several advantages for applications that require custom graphics and user interface elements.

*High Resolution: It provides a relatively high pixel density, allowing for the display of detailed graphics and images. This can enhance the visual appeal and clarity of the displayed content.

*Customization: A graphic LCD module allows for the individual control of each pixel, enabling the creation of custom graphics, icons, and user interface elements.

*Versatility: The ability to display custom graphics and images makes a 128x64 graphic LCD module suitable for a wide range of applications.

*User Interaction: The display of custom graphics and user interface elements allows for intuitive user interaction. It enables the presentation of buttons, menus, sliders, and other interactive elements, enhancing user experience and usability.

*Information Display: The high resolution enables the presentation of detailed information, such as graphs, charts, and data plots.

*Low Power Consumption: Graphic LCD modules generally consume less power compared to other display technologies like TFT-LCDs.

*Compact Size: This module is available in compact form factors, making it suitable for applications with limited space constraints.

*Cost-Effective: Graphic LCD modules are often more cost-effective compared to higher-resolution displays like TFT-LCDs.

Applications

It is a 128x64 dot matrix LCD screen with high image quality, wide viewing angle. All materials comply with environmental protection requirements and RoHS standards. This module is widely used in smart equipment, communication equipment, medical equipment, industrial control equipment, aerospace, security, furniture equipment, and various instruments, such as evaluation instruments, power system equipment, laboratory instruments, medical instruments, fire protection systems, temperature and humidity transmissions, pressure transmissions, analytical instruments, environmental protection testing instruments, etc. And the versatility and graphical capabilities of this module make it suitable for a wide range of applications where custom graphics and user interfaces are needed.

Our Service

1. Best Quality Control : Every LCD tested with special instruments or main boards before delivery to ensure working.

2. Correct Packaging Way: Packed in anti-static bags with foam box to ensure safety in transportation.

3. Multiple Payment Methods: T/ T, Western Union,L/ C, PayPal.

4. Reliable Shipping Methods: Prompt delivery by UPS, EMS, DHL, TNT, or by air.

5. Professional Customized Service: Professional team provide OEM&ODM service.

6. Competitive Price: Give you a direct factory price.

7. Better After-sales Service: Long for one year warranty.
