No Backlight Character LCD Module For Industrial Instruments Positive / Negative Mode

No Backlight Character LCD Module For Industrial Instruments Positive / Negative Mode
No Backlight Character LCD Module For Industrial Instruments Positive / Negative Mode No Backlight Character LCD Module For Industrial Instruments Positive / Negative Mode

Large Image :  No Backlight Character LCD Module For Industrial Instruments Positive / Negative Mode

Product Details:
Place of Origin: CHINA
Brand Name: ROYAL DISPLAY
Certification: SGS ROHS
Model Number: RYB2002B
Payment & Shipping Terms:
Minimum Order Quantity: 500pcs
Price: Negotiable
Packaging Details: 130pcs/CTN 7.0Kg L45*W36*H32CM
Delivery Time: 25~28 Working Days
Supply Ability: 500k/Month
Detailed Product Description
Product Name: STN 20x2 Character LCD Module RYB2002A Building In Japanese Russian And Other Kinds Of Different Characters Model No.: RYB2002B
LCD Type: STN LED Backlight: White
High Light:

Lcd Display Module

,

Oled Character Display





STN 20x2 Character LCD Module RYB2002B Building in Japanese Russian and Other Kinds of Different Characters



Item Description
Product Name 20x2 COB LCD Module
Model No. RYB2002B
Dot Format 20 x 2
Outline Dimension(mm) 180.0 x40.0MAX
Assem. Size(mm) 172.0 x 32
Viewing Area(mm) 149.0 x 23
Character Size( mm) 9.5 x 5.9
Viewing Angle 6 O' clock
LCD Type STN-Gray, STN-blue VA
Backlight White LED backlight or No backlight
Driver IC ST7066U
Power supply 5V
Interface Parallel
Operating Temp -20º C~70º C
Storage Temp -30º C~80º C

1. Typical Applications:

Telephone, Home Automation, Industrial Instruments, Price Tag, Printer, Fax, etc



2. Features:



Transmissive, Transflective and Reflective Mode

Duty Ratio: 1:8~1:34 for one to four line characters

Wide Operation & Storage temperature range

High reliability

Low power consumption
