132X55 Dots Graphic LCD Module With White / Amber LED Backlight

132X55 Dots Graphic LCD Module With White / Amber LED Backlight
132X55 Dots Graphic LCD Module With White / Amber LED Backlight 132X55 Dots Graphic LCD Module With White / Amber LED Backlight 132X55 Dots Graphic LCD Module With White / Amber LED Backlight

Large Image :  132X55 Dots Graphic LCD Module With White / Amber LED Backlight

Product Details:
Place of Origin: CHINA
Brand Name: ROYAL DISPLAY
Certification: SGS ROHS
Model Number: RYG13255A
Payment & Shipping Terms:
Minimum Order Quantity: 500pcs
Price: Negotiable
Packaging Details: 220pcs/CTN 11Kg L45*W36*H32CM
Delivery Time: 25~28 Working Days
Supply Ability: 300k/Month
Detailed Product Description
Product Name: RYG13255A COG Graphic LCD Module Model No.: RYG13255A
Dot Format: 132X55 Viewing Angle: 6 O' Clock
Operating Temp: -20º C~70º C LCD Type: STN Postive
Driver: ST7567
High Light:

Lcd Graphic Display Module

,

Transflective Lcd Display



132X55 Dots With ST7567 RYG13255A COG Graphic LCD Module FSTN Positive Black On White



Item Description
Product Name 132*55 dots Graphic LCD Module
Model No. RYG13255A
Dot Format 132*55
Outline Dimension(mm) 78*47
Viewing Area(mm) 74*35
Pixel Size( mm) 0.43 x 0.42
Viewing Angle 6 O' clock
LCD Type FSTN-Positive, STN-Gray
Backlight White or Amber LED backlight
Driver IC ST7567
Power supply 3.3V
Interface Parallel
Operating Temp -20º C~70º C
Storage Temp -30º C~80º C



Typical Applications:

Clusters, Car Radios, Air conditioner, Home Automation, Industrial Instruments, etc

Features:
Transmissive, Transflective and Reflective Mode

Duty Ratio: up to 1:240

support gray scale display

Wide Operation & Storage temperature range



132X55 Dots Graphic LCD Module With White / Amber LED Backlight 0

132X55 Dots Graphic LCD Module With White / Amber LED Backlight 1
