Transflective Positive RYP1286408 COB LCD Module FSTN 1/65 Bias

Transflective Positive RYP1286408 COB LCD Module FSTN 1/65 Bias
Transflective Positive RYP1286408 COB LCD Module FSTN 1/65 Bias

Large Image :  Transflective Positive RYP1286408 COB LCD Module FSTN 1/65 Bias

Product Details:
Place of Origin: CHINA
Brand Name: ROYAL DISPLAY
Certification: ROHS
Model Number: RYP1286408
Payment & Shipping Terms:
Minimum Order Quantity: 100pcs
Price: please contact us
Packaging Details: Cartons, Capboard, EPE, Blister Tray.
Delivery Time: 25~28 Working Days
Payment Terms: L/C, T/T, Western Union, MoneyGram
Supply Ability: 150K/Month
Detailed Product Description
Display Type: FSTN Gray, Transflective, Positive Type: COB
Size: 68*36.5*9.5mm Driver Method: 1/9duty 1/65 Bias
Viewing Direction: 6 O'clck Operating Temp.: -40℃~+70℃
Stroage Temp.: -40℃~+80℃ Color: Mono,Custom
High Light:

RYP1286408 COB LCD Module

,

Transflective Positive COB LCD Module

,

1/65 Bias Panel Lcd Monitor

RYP1286408 Custom COB Type LCD Module FSTN Display Screen for UPS Power


PRODUCT DESCRIPTION


* RYP1286408 is a liquid crystal display Module (LCM).

* It is composed of a LCD Display Module.

* RoHS & REACH compliant.

* If you can't find a suitable one, contact us to get a recommendation.

Item Description
Model No. RYP1286408
Display Type FSTN Gray, Transflective, positive
Outline (mm) 68*36.5*9.5mm
Viewing Angle 6 O' clock
Driver method 1/9duty 1/65bias
Operating Voltage 3.3V
Connector PIN
Operating Temp -40º C~70ºC
Storage Temp -40º C~80ºC


Transflective Positive RYP1286408 COB LCD Module FSTN 1/65 Bias 0
Transflective Positive RYP1286408 COB LCD Module FSTN 1/65 Bias 1

Graphic LCDs

Graphic LCDs can display fully changeable graphics. It is a common option for applications that need to display many different menus or need the ability to display several different fonts and font sizes. In addition to the changing graphics, it also can provide optimal sunlight readability with low power consumption.


Features

Wide variety of off the shelf sizes and resolutions

Most products kept in stock and can ship same day

Ability to display fully changeable graphics

Sunlight readable

Low power consumption

Fully customizable

Graphic LCD Module, LCD display, 128x64 LCD module, LCD screen, COB LCD module, Monochrome LCD, Mono LCD display, Segment LCD display, Customized LCD Module, RYP1286408, LCD Module for Interver UPS
