240X160 dots STN UC1611S With White Color Monochrome Graphic Touch Screen Module LCD Cog Module

Certification
China Royal Display Co.,Limited certification
China Royal Display Co.,Limited certification
Customer Reviews
Royal Display, Perfect LCD Supplier, Fast response, thanks for cooperation.

—— Beata from Poland

Received the lcds today, no damage and test well, thanks.

—— Natalya Kryukova from Russia

Fast delivery and good quality, I am happy with Royal Display, I will order more later.

—— Meerimgul from Turkey

High quality screen, fast service.

—— Daniel Castelo from Switzerland

I'm Online Chat Now

240X160 dots STN UC1611S With White Color Monochrome Graphic Touch Screen Module LCD Cog Module

240X160 dots STN UC1611S With White Color Monochrome Graphic Touch Screen Module LCD Cog Module
240X160 dots STN UC1611S With White Color Monochrome Graphic Touch Screen Module LCD Cog Module 240X160 dots STN UC1611S With White Color Monochrome Graphic Touch Screen Module LCD Cog Module 240X160 dots STN UC1611S With White Color Monochrome Graphic Touch Screen Module LCD Cog Module 240X160 dots STN UC1611S With White Color Monochrome Graphic Touch Screen Module LCD Cog Module 240X160 dots STN UC1611S With White Color Monochrome Graphic Touch Screen Module LCD Cog Module 240X160 dots STN UC1611S With White Color Monochrome Graphic Touch Screen Module LCD Cog Module

Large Image :  240X160 dots STN UC1611S With White Color Monochrome Graphic Touch Screen Module LCD Cog Module

Product Details:
Place of Origin: China
Brand Name: ROYAL DISPLAY
Certification: ROHS, ISO
Model Number: RYB240160A
Payment & Shipping Terms:
Minimum Order Quantity: 100pcs
Price: USD 2.3-3.2
Packaging Details: Cartons, Capboard, EPE, Blister Tray
Delivery Time: 15-20 work days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 300K/M
Detailed Product Description
DOT Format: 240X160 Outline (mm): 77*53
IC Package: Cog Backlight Color: White Color
Display Type: FSTN-LCD Grey Power Supply: 3.3V
Interface: Parallel Backlight Current (Typ): 51mA
View Angle Range: No Connector: FFC-Connector
Appearance: Black On White Viewing Direction: 12:00
High Light:

UC1611S Graphic Touch Screen Module

,

STN Graphic Touch Screen Module

,

240X160 LCD Cog Module

Graphic Touch Screen LCD COG Module 240x160 Display


Product Description
1. 240x160dots
2. Parallel interface
3. Ultra high contrast, YG & White LED backlight as option
4. STN-YG, STN-blue, STN-Gray, FSTN-Positive display results as option



Item Description
Product Name 240x160dots Graphic LCD Module
Model No. RYB240160A
Dot Format 240x160
Outline (mm) 77*53
Viewing Area(mm) 12:00
Pixel Size( mm) 0.43 x 0.42
Viewing Angle 12 O' clock
LCD Type FSTN-Positive, STN-Gray
Backlight White or Amber LED backlight
Driver IC UC1611S
Power supply 3.3V
Interface Parallel
Operating Temp -20º C~70ºC
Storage Temp -30º C~80ºC







What can we custom?



1.LCD type: VA/TN/HTN/STN Yellow-Green/STN Gray/STN Blue/FSTN/DFSTN

2.Display form: LCD panel/COB/COG/COF

3.Polarizer: Transflective, Transmissive, Reflective

4.Backlight: Green, Gray, Yellow-Green, Blue, Black, White, Orange/Amber, others

5.Operating temperature: 0 to +50°C, -10 to +60°C, -20 to +70℃,-30 ℃ +85 ℃, others

6.Connector/Connection: Metal PIN, Rubber/Zebra, Heat seal, FPC, FFC





Production Lines



240X160 dots STN UC1611S With White Color Monochrome Graphic Touch Screen Module LCD Cog Module 0



240X160 dots STN UC1611S With White Color Monochrome Graphic Touch Screen Module LCD Cog Module 1





Applications



240X160 dots STN UC1611S With White Color Monochrome Graphic Touch Screen Module LCD Cog Module 2
