Product Details:
Payment & Shipping Terms:
|
| Product Type: | Module | Resolution: | 320 RGB X 240 |
|---|---|---|---|
| Module Size(mm): | 76.9(W) X 63.9(H) X 3.26(D) | Active Area(mm): | 70.08(H) X 52.56(V) |
| Viewing Angle: | 6 O’clock | Interface: | 54 Pin FPC, Parallel 24bit RGB |
| High Light: | Lq035nc111 TFT LCD Module,3.5in TFT LCD Module,54 Pin FPC Lcd Monitor Module |
||
Innolux's employees worldwide number more than 60,000, and its production sites and sales locations span the globe.
With its major TFT plants located in Zhunan and Tainan, both in Taiwan, Innolux has also established overseas
module plants in the Chinese cities of Ningbo, Nanjing, Foshan, and Shanghai. Innolux's extensive global presence
allows it to quickly provide a full range of services to its customers, reducing logistics and manpower costs, while
achieving the environmental objectives of energy conservation and reduced carbon emissions. Innolux's unique
intelligent management platform has not only enhanced the company's management capabilities, but also provides
customers with prompt, accurate delivery information. This is just one of the ways we are constantly striving to boost
customer satisfaction.
| Item | Description |
| Model Name | LQ035NC111 |
| Product type | LCD Module |
| Screen Size | 3.45" |
| Aspect Ratio | 4:3 |
| Resolution | 320 RGB x 240 |
| Module Size(mm) | 76.9(W) x 63.9(H) x 3.26(D) |
| Active Area(mm) | 70.08(H) x 52.56(V) |
| Viewing Angle (Tpy.)θT/θB/θL/θR | 60/60/50/55 |
| Luminance(nits) | 300 |
| Contrast Ratio | 400 |
| Response Time(ms) | 25 |
| Weight (g) | 30 |
| Interface | 54pin FPC, Parallel 24bit RGB |
| Operation Temperature( ºC) | -20º C~70ºC |
| Storage Temperature (ºC) | -30º C~80ºC |
| HTHH.(op) | 60ºC 90%RH 240h |
OUR SERVICE ADVANTAGES
1). Quality Control: Every LCD tested with special instruments or main boards before delivery to ensure working. Both Original and High quality OEM products available.
2). Packing: Packed in anti-static bags with foam box to ensure safety in transportation.
3). Payment Terms: T/T, Western Union.
4). Shipping Methods: Prompt delivery by UPS, EMS, DHL, TNT, or by air.
5). Service: Best after-sales service to ensure satisfaction from customers.
6). Delivery: Goods will be delivered with 2-4 days by DHL, UPS, TNT, EMS, or By Air
7). Warranty: Usually, product warranty for one year.
8). Samples: Our company offers samples for quality test or other business purposes, but we kindly ask you to pay for samples and the freight.
TFT Advantages
1.High quality of TFT LCD screens.
2.The visible area of TFT LCD screens is large.
3.TFT LCD screens have a wide range of applications.
4.TFT LCD screens have no electromagnetic radiation.
5.TFT LCD screens digital interface.
6.TFT LCD screens "figure" symmetrical and small.
7. The effect of TFT LCD screens is good
8. Low power consumption of TFT LCD screens
